Wiring diagrams and electrical functions Earths - wiring diagram
EARTHS - WIRING DIAGRAM
1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 10/2000, up to 10/2000
Wiring diagram
COMPONENTS
Component code Name Assembly reference C1 Battery earth C1 Battery earth Op. 5530B BATTERY AND LEADS C10 Front left earth C12 ABS front earth C15 Facia earth, driver''s side C30 Left rear earth C40 Earth on engine C50 Air Bag earth C53 Side Bag + Head Bag earth C54 Pretensioner earth C60 Injection ECU earth
1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 12/03
Wiring diagram
COMPONENTS
Component code Name Assembly reference C1 Battery earth C1 Battery earth Op. 5530B BATTERY AND LEADS C10 Front left earth C12 ABS front earth C15 Facia earth, driver''s side C30 Left rear earth C40 Earth on engine C50 Air Bag earth C53 Side Bag + Head Bag earth C54 Pretensioner earth C60 Injection ECU earth
1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005
Components
Component code Description Reference to the assembly A001 BATTERY Op. 5530B BATTERY AND LEADS C1 BATTERY EARTH C2 BATTERY EARTH ON ENGINE C3 BATTERY EARTH ON BODYSHELL C10 LEFT FRONT EARTH C011 RIGHT FRONT EARTH C012 ABS FRONT EARTH C15 DASHBOARD EARTH, DRIVER''S SIDE C030 LEFT REAR EARTH C39 COMPRESSOR EARTH C40 ENGINE EARTH C50 AIR BAG EARTH C60 INJECTION ECU EARTH C62 METHANE INJECTION CONTROL UNIT EARTH
19 Electrical
