Supply - wiring diagram

Make

Fiat

Model

Doblò Factory Service Manual

Year

2000–2010

Section

Power supply and earths › Supply - wiring diagram

Wiring diagrams and electrical functionsSupply - wiring diagram

SUPPLY - WIRING DIAGRAM

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 10/2000, up to 10/2000

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
A1	Battery	Op. 5530B BATTERY AND LEADS
A20	Starter'' motor	Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL
A20	Starter'' motor	Op. 5520B STARTER MOTOR AND COMPONENTS
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C1	Battery earth
C1	Battery earth	Op. 5530B BATTERY AND LEADS
C10	Front left earth
C15	Facia earth, driver''s side
C40	Earth on engine
H1	Ignition switch	Op. 5520A IGNITION SWITCH

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 12/03

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
A1	Battery	Op. 5530B BATTERY AND LEADS
A20	Starter'' motor	Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL
A20	Starter'' motor	Op. 5520B STARTER MOTOR AND COMPONENTS
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C1	Battery earth
C1	Battery earth	Op. 5530B BATTERY AND LEADS
C10	Front left earth
C15	Facia earth, driver''s side
C40	Earth on engine
H1	Ignition switch	Op. 5520A IGNITION SWITCH
