Diagnostic socket connections
- Make
- Fiat
- Model
- Scudo Factory Service Manual
- Year
- 1996–2006
- Section
- Wiring diagrams (2002 update) › Diagnostic socket connections
55 Electrical equipmentDiagnostic socket connections
Diagnostic socket connections
* See 1868 D engine cooling wiring diagram
** Variant connections for versions with CPH
*** Variant connections for version without Air Bag
