Wiring diagrams and electrical functionsHeadlamp washer wiring diagram
HEADLAMP WASHER WIRING DIAGRAM
Wiring Diagram
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B001 | Engine compartment junction unit | 5505A |
| B002 | Junction unit under dashboard | |
| C011 | Right front earth | |
| C022 | Centre dashboard earth | |
| D001 | ||
| D098 | ||
| E050 | Instrument panel | |
| H001 | Ignition switch | |
| H005 | Steering column switch unit | 5550A |
| M001 | Body computer | |
| M065 | Info-telematic control unit (NIT) | 5580P |
| M079 | 5050B |
