Sun roof location components
- Make
- Lancia
- Model
- Thesis Factory Service Manual
- Year
- 2002–2009
- Section
- Electrically activated devices › Sun roof location components
Wiring diagrams and electrical functionsSun roof location components
SUN ROOF LOCATION COMPONENTS
Location Components
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C015 | Driver''s dashboard earth | |
| C022 | Centre dashboard earth | |
| D020 | ||
| D097 | Short circuit coupling | |
| H001 | Ignition switch | |
| H060 | Sun roof switch | |
| K125 | RAIN, DUSK AND MISTING SENSOR | |
| M001 | Body computer | |
| M062 | 7040E | |
| M064 | Passive entry control unit (NPE) | 5580E |
| M095 | Sun roof control unit | 7030B |
| P093 | Aerial for alarm and central locking receiver |
Location Components
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C015 | Driver''s dashboard earth | |
| C020 | ||
| C022 | Centre dashboard earth | |
| D020 | ||
| D097 | Short circuit coupling | |
| H001 | Ignition switch | |
| H060 | Sun roof switch | |
| K125 | RAIN, DUSK AND MISTING SENSOR | |
| M001 | Body computer | |
| M062 | 7040E | |
| M064 | Passive entry control unit (NPE) | 5580E |
| M095 | Sun roof control unit | 7030B |
| P015 | Passive entry control unit RF aerial (NPE) |
