HEATED SEATS WIRING DIAGRAM

Wiring Diagram

Components

Component code	Name	Assembly reference
B002	Junction unit under dashboard
B045	Luggage compartment junction unit (CVB)	5505A
C015	Driver''s dashboard earth
C020
C022	Centre dashboard earth
C030	Left rear earth
C031	Right rear earth
D032
D070	Driver''s seat coupling
D071	Passenger seat coupling
D097	Short circuit coupling
D130
D131	Right rear backrest cushion coupling
D132	Rear armrest backrest coupling
D133	Left front backrest cushion coupling
D134	Right front backrest cushion coupling
I065
I066
M001	Body computer
M063	Luggage compartment control unit (NVB)
M065	Info-telematic control unit (NIT)	5580P
M076	Seats/mirrors with memory control unit
M110	Front passenger seat heater control unit
M111
M112	Right rear seat heater control unit
O042	Left rear seat heater pad with sensor	7050M
O043	Right rear seat heater pad with sensor	7050M
O044	Left rear seat backrest heater pad	7050M
O045	Right rear seat backrest heater pad	7050M
O046
O047	Right front seat heater pad with sensor	7045M
O048	Left front backrest heater pad	7045M
O049		7045M
