Heated seats location components
- Make
- Lancia
- Model
- Thesis Factory Service Manual
- Year
- 2002–2009
- Section
- Electrically activated devices › Heated seats location components
Wiring diagrams and electrical functionsHeated seats location components
HEATED SEATS LOCATION COMPONENTS
Location Components
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C015 | Driver''s dashboard earth | |
| C020 | ||
| C022 | Centre dashboard earth | |
| C030 | Left rear earth | |
| C031 | Right rear earth | |
| D032 | ||
| D070 | Driver''s seat coupling | |
| D071 | Passenger seat coupling | |
| D097 | Short circuit coupling | |
| D130 | ||
| D131 | Right rear backrest cushion coupling | |
| D132 | Rear armrest backrest coupling | |
| D133 | Left front backrest cushion coupling | |
| D134 | Right front backrest cushion coupling | |
| I065 | ||
| I066 | ||
| M001 | Body computer | |
| M063 | Luggage compartment control unit (NVB) | |
| M065 | Info-telematic control unit (NIT) | 5580P |
| M076 | Seats/mirrors with memory control unit | |
| M110 | Front passenger seat heater control unit | |
| M111 | ||
| M112 | Right rear seat heater control unit | |
| O042 | Left rear seat heater pad with sensor | 7050M |
| O043 | Right rear seat heater pad with sensor | 7050M |
| O044 | Left rear seat backrest heater pad | 7050M |
| O045 | Right rear seat backrest heater pad | 7050M |
| O046 | ||
| O047 | Right front seat heater pad with sensor | 7045M |
| O048 | Left front backrest heater pad | 7045M |
| O049 | 7045M |
