Lancia Thesis Factory Service Manual (2002-2009)19 · Wiring diagrams and electrical functions
19 · Electrical

Horns wiring diagram

Make
Lancia
Model
Thesis Factory Service Manual
Year
2002–2009
Section
Electrically activated devices › Horns wiring diagram
Wiring diagrams and electrical functionsHorns wiring diagram

HORNS WIRING DIAGRAM

Wiring Diagram

HORNS WIRING DIAGRAM

Components

Component codeNameAssembly reference
B001Engine compartment junction unit5505A
C011Right front earth
C022Centre dashboard earth
D110CLOCK SPRING AND STEERING WHEEL CONTROLS COUPLING
H005Steering column switch unit5550A
P010Avvisatore acustico tono alto
P011Avvisatore acustico tono basso
