TD5 Defender
PANEL REPAIRS
7
REPAIR
BODY SIDE REAR - LOWER - ASSEMBLY
In this procedure the Body Side Capping and the
Corner Capping are also changed.
Remove
1. Disconnect both battery leads, negative lead
first.
2. Remove body side upper rear. See this
Section.
3. Remove all rear lamps and reflectors.
4. LH side: Remove number plate and lamp.
5. LH side: Remove tail door striker.
6. RH side: Remove fuel filler and grommet.
7. Remove all bolts and rivets securing lower body
side assembly.
Refit
8. Prepare and clean panel joint faces.
9. Reverse removal procedure.
NOTE: When refitting, ensure body side
upper is correctly fitted onto location pins.
