Discovery II
DRIVING AIDS
REPAIRS 86-8-13
REPAIRS
Control unit (ECU) - park distance
control (PDC)
$% 86.54.10
Remove
1. Remove loadspace LH side trim casing access
panel.
2. Remove 2 bolts securing parking aid ECU
mounting bracket to body and manoeuvre ECU
and bracket assembly from behind trim casing.
3. Disconnect multiplug from ECU.
4. Remove 2 nuts securing ECU to bracket.
5. Remove ECU.
Refit
1. Fit ECU to mounting bracket and fit and tighten
nuts.
2. Connect ECU multiplug.
3. Manoeuvre ECU and mounting bracket
assembly behind trim casing, align, fit bolts and
tighten to 25 Nm (18 lbf.ft).
4. Fit access panel.
