Discovery II
DRIVING AIDS
REPAIRS 86-8-15
Sensor - parking aid - rear - inner
$% 86.54.23
Remove
1. Remove rear bumper assembly.
Bumper assembly - rear - from 03MY.
2. Remove 7 bolts and 5 screws securing closing
panel and remove panel.
3. Disconnect multiplug from sensor.
4. Release and remove sensor and sensor
housing.
Refit
1. Clean sensor location on bumper.
2. Fit sensor housing to bumper, ensuring lug on
housing is aligned with cut-out in bumper.
3. Fit and secure sensor to housing.
4. Connect multiplug.
5. Fit closing panel and secure with bolts and
screws.
6. Fit bumper assembly.
