Discovery II
DRIVING AIDS
86-8-16 REPAIRS
Sensor - parking aid - rear - outer
$% 86.54.24
Remove
1. Remove tail lamp from bumper.
LIGHTING, REPAIRS, Lamp - tail/
2. Disconnect multiplug from sensor.
3. Release and remove sensor and sensor
housing.
Refit
1. Clean sensor location on bumper.
2. Fit sensor housing to bumper, ensuring lug on
housing is aligned with cut-out in bumper.
3. Fit and secure sensor to housing.
4. Connect multiplug.
5. Fit tail lamp.
