300Tdi Discovery
57
STEERING
8
REPAIR
7. Loosen clamp securing reservoir hose to
steering pump, disconnect hose.
8. Disconnect high pressure pipe from steering
pump.
CAUTION: Plug the connections.
9. Remove 4 bolts securing steering pump to
mounting bracket, remove pump.
NOTE:
Do not carry out further
dismantling if component is removed for
access only.
10. Remove 3 bolts securing mounting plate to
pump, remove plate.
11. Fit mounting plate to replacement steering
pump. Tighten bolts to
9 Nm.
Refit
12. Position steering pump, fit 3 bolts. Tighten to
35
Nm.
13. Connect high pressure pipe to steering pump.
Tighten to
20 Nm.
14. Connect reservoir hose to steering pump.
Tighten clamp to
3 Nm.
15. Position pulley to steering pump, coat threads of
bolts with Loctite 242; fit but do not fully tighten 3
bolts.
16. Fit drive belt.
See ENGINE, Repair, Drive Belt
17. Restrain steering pump pulley, tighten bolts to
10
Nm.
18. Fit fan blades and viscous coupling.
See
COOLING SYSTEM, Repair, Viscous
Coupling, Fan Blades, Pulley and Fan Cowl
19. Fit undertray.
20. Bleed power steering system.
See Power
Steering System - Bleed
