300Tdi Discovery
57
STEERING
14
REPAIR
Refit
20. Manoeuvre upper column to position in footwell,
ensure splines in column and universal joint are
correctly engaged and rubber boot is fitted.
21. Fit but do not tighten universal joint pinch bolt.
22. Position upper column to upper mounting, fit
washers and nuts, do not tighten nuts.
23. Fit but do not tighten nuts and bolts securing
upper column to lower mounting.
24. Fit lower mounting steady bracket, fit but do not
tighten nuts and bolts.
25. Ensure upper column is aligned to mountings.
26. Tighten all nuts and bolts to
22 Nm.
27. Tighten universal joint pinch bolt to
25 Nm.
28. Connect column switch multiplug.
29. Connect ignition switch multiplugs.
30. Fit rotary coupler.
See SUPPLEMENTARY
RESTRAINT SYSTEM, Repair, Rotary
Coupler
31. Fit steering wheel.
See Steering Wheel
32. Reconnect battery negative lead.
33. Check steering column lock for correct
operation, tighten shear bolts until heads shear
off.
34. If fitted - position knee bolster, fit and tighten
screws.
35. Fit steering column shroud.
See Steering
Column Shroud
36. Fit driver’s access panel.
