L322 Range Rover Service Procedures
CAPACITIES, FLUIDS, LUBRICANTS AND SEALANTS
09-3
Lubrication
General
The engine and other lubricating systems are filled
with high performance lubricants giving prolonged
life.
CAUTION: Always use a high quality oil of the
correct viscosity range in the engine. The use of
oil of the incorrect specification can lead to high
oil and fuel consumption and ultimately to
damaged components.
Oil to the correct specification contains additives
which disperse the corrosive acids formed by
combustion and prevent the formation of sludge
which can block the oil ways. Additional oil additives
should not be used.
Always adhere to the recommended servicing
intervals.
Engine oil viscosity
The above chart indicates the ambient temperature
ranges which each engine oil viscosity is suitable for.
Engine oil - Td6
Use either a 5W/30, 5W/40, 5W/50 or 10W/40 oil,
meeting specifications ACEA - A3/B3; and having a
viscosity band recommended for the temperature
range of your locality.
Engine oil - V8
Use either a 0W/30, 0W/40, 5W/30 or 5W/40 oil,
meeting specifications ACEA - A3/B3; (API: SJ/CD,
ECII for NAS market), and having a viscosity band
recommended for the temperature range of your
locality.
GM Automatic Gearbox oil
Use only Texaco ETL-7045E.
ZF Automatic Gearbox oil
Use only Esso ATF LT 71141.
Transfer box
Use only Castrol BOT 26 FMB 1
Front and rear differential
Use only Castrol SAF-X0.
Power steering
Use only Texaco Cold Climate PSF 14315 fluid
Air Conditioning
Use lubricating oil Nippon Denso ND-8.
General Greasing
Use Multipurpose Lithium Base Grease N.L.G.I.
consistency No. 2.
