L322 Range Rover Service Procedures
FINAL DRIVE
51-4
REPAIRS
10. Disconnect breather hose from differential.
11. Drain oil from differential.
FINAL DRIVE, ADJUSTMENTS, Rear
differential - drain and refill.
12. Reference mark drive shaft and differential
flanges to aid reassembly.
13. Remove 6 bolts securing drive shaft to
differential drive flange and collect 3 bolt plates.
Discard bolts.
14. Position jack to support the lower arm.
15. Remove nut and bolt securing lower arm to
hub.
16. Remove support jack
17. Release the lower arm from hub and
disconnect drive shaft from differential.
18. Repeat procedure for other side.
19. Support weight of differential assembly on a
jack.
M51 0120
