Range Rover V8 Fuel Tank Repairs - L322 Service Procedures Page 367
FUEL DELIVERY SYSTEM - V8
REPAIRS 19-2-11
17. Disconnect fuel tank filler hose from fuel tank
filler neck.
18. Remove 2 screws securing fuel filter and
release fuel filter from mounting brackets.
19. Position container to catch fuel spillage.
20. Disconnect 3 fuel hoses and 1 reference pipe,
remove fuel filter.
WARNING: The spilling of fuel is
unavoidable during this operation. Ensure
that all necessary precautions are taken to
prevent fire and explosion.
21. Remove container.
22. With assistance remove 5 bolts securing fuel
tank to body, lower and remove tank.
NOTE: Pull vent and breather hoses through
body while lowering fuel tank.
NOTE: Do not carry out further dismantling if
component is removed for access only.
