Range Rover P38
33
CLUTCH
NEW RANGE ROVER
6
REPAIR
MASTER CYLINDER
Service repair no - 33.20.01
Remove
1. Remove fascia closing panel.
See CHASSIS
AND BODY, Repair.
2. Remove 4 scrivets securing lower closing panel.
Disconnect multiplug from footwell lamp.
Remove panel.
3. Remove spring clip and clevis pin from master
cylinder push rod.
4. Position cloth beneath master cylinder to absorb
fluid spillage.
CAUTION: Do not allow brake fluid to
contact painted surfaces. Paint damage
will occur. If spilled, remove fluid. Wash
area with clean warm water.
5. Disconnect reservoir hose from master cylinder.
Plug hose and connection.
6. Disconnect pressure pipe from master cylinder.
Plug pipe and connection.
7. Remove 2 nuts securing master cylinder to
bulkhead. Remove master cylinder.
Refit
8. Ensure mating faces are clean.
9. Reverse removal procedure.
10. Bleed clutch system.
See this section.
