Abs6 brake system components (Brakes) (page 3 of 3)

Make

Rover

Model

Coupé, Cabriolet & Tourer 200/400 Coupé, Cabriolet & Tourer Workshop Manual

Section

Description and operation

BrakesAbs6 brake system components · page 3 of 3

1. Servo assembly
2. Master cylinder
3. Brake fluid reservoir
4. Hydraulic modulator
5. Hydraulic pump and motor
6. Reluctor ring – 50 teeth
7. Speed sensor – detects wheel speed and acceleration or deceleration and informs the ECU
8. Warning lamp – informs the driver that the system has been shut down due to a fault being detected.
9. ECU
10. Hydraulic pump relay/fuse box
11. Handbrake switch
12. ABS6 diagnostic socket
13. ABS6 failsafe relays
