Sunroof Frame Replacement

Make

Vauxhall

Model

Astra J

Section

Sunroof › Repair Instructions › Sunroof Frame Replacement

RoofSunroof Frame Replacement

Sunroof Frame Replacement Callout Component Name Preliminary Procedures 1. Remove the headlining trim panel. Refer to . Headlining Trim Panel Replacement 2. Remove the sunroof window. Refer to . Sunroof Window Replacement 3. Remove the sunroof air deflector cover. Refer to . Sunroof Air Deflector Cover Replacement 4. Remove the sunroof sunshade. Refer to . Sunroof Sunshade Replacement 5. Remove the sunroof window motor. Refer to . Sunroof Window Motor Replacement 6. Remove the sunroof air deflector. Refer to . Sunroof Air Deflector Replacement 7. Remove the Sunroof Housing Drain Gutter. Refer to . Sunroof Housing Drain Gutter Replacement 8. Disconnect the Front and Rear Drain Hose. 1 Sunroof Module Bolt (Qty: 12) Caution: Refer to Fastener Caution . Tighten 9 N·m (80 lb in) 2 Sunroof Frame Procedure With the aid of an assistant, lower the sunroof frame and remove the sunroof frame out through the passenger side door.
