D259 instrument panel bridge coupling

Make

Fiat

Model

500 Factory Service Manual

Year

2007–2024

Section

Intermediate couplings › D259 instrument panel bridge coupling

Connectors and pin-outsD259 instrument panel bridge coupling

D259 INSTRUMENT PANEL BRIDGE COUPLING

1.2 8v, 1.3 Multijet, 1.4 16v · VDC/ESP system

Wiring	Colour
See 153 INSTRUMENT PANEL BRIDGE	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0.35	BV		See H115 ADDITIONAL CONTROL PANEL	1
2	0.35	LB		See H115 ADDITIONAL CONTROL PANEL	2
3	0.5	N		See H115 ADDITIONAL CONTROL PANEL	3
4	0.35	BM		See H115 ADDITIONAL CONTROL PANEL	6
5	0.35	HB		See H115 ADDITIONAL CONTROL PANEL	5
6	0.35	HM		See H115 ADDITIONAL CONTROL PANEL	4

1.2 8v, 1.3 Multijet, 1.4 16v

Wiring	Colour
See 153 INSTRUMENT PANEL BRIDGE	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0.35	BV		See H115 ADDITIONAL CONTROL PANEL	1
2	0.35	LB		See H115 ADDITIONAL CONTROL PANEL	2
3	0.5	N		See H115 ADDITIONAL CONTROL PANEL	3
5	0.35	HB		See H115 ADDITIONAL CONTROL PANEL	5

1.2 8v, 1.3 Multijet, 1.4 16v · VDC/ESP system

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0.35	BV		See M001D BODY COMPUTER (DASHBOARD)	3
2	0.35	LB		See M001E BODY COMPUTER (DASHBOARD)	16
3	0.35	N		See C015 DASHBOARD EARTH, DRIVER'S SIDE	1
4	0.35	HM		See D001 FRONT/DASHBOARD COUPLING	6
5	0.35	HB		See M001D BODY COMPUTER (DASHBOARD)	12
6	0.35	BM		See D001 FRONT/DASHBOARD COUPLING	7

1.2 8v, 1.3 Multijet, 1.4 16v

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0.35	BV		See M001D BODY COMPUTER (DASHBOARD)	3
2	0.35	LB		See M001E BODY COMPUTER (DASHBOARD)	16
3	0.35	N		See C015 DASHBOARD EARTH, DRIVER'S SIDE	1
5	0.35	HB		See M001D BODY COMPUTER (DASHBOARD)	12
