A001 battery

Make

Fiat

Model

500 Factory Service Manual

Year

2007–2024

Section

Starting - recharging › A001 battery

Connectors and pin-outsA001 battery

A001 BATTERY

A001A – Battery negative

1.2 8v, 1.4 16v

Wiring	Colour
See 40 BATTERY NEGATIVE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	16	N		See C003A BATTERY EARTH ON BODYSHELL (BATTERY NEGATIVE)	1

1.3 Multijet

Wiring	Colour
See 40 BATTERY NEGATIVE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	35	N		See C003A BATTERY EARTH ON BODYSHELL (BATTERY NEGATIVE)	1

A001B – Front

1.3 Multijet

Wiring	Colour
See 12 FRONT

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	6	N	X	See K101A FUEL TEMPERATURE AND WATER IN FUEL FILTER SENSOR (FRONT)	2
				See M015B PLUG PREHEATING CONTROL UNIT (FRONT)	1
				See M010A ENGINE MANAGEMENT ECU (FRONT)	1
				See M010A ENGINE MANAGEMENT ECU (FRONT)	2
				See M010A ENGINE MANAGEMENT ECU (FRONT)	3

1.4 16v

Wiring	Colour
See 12 FRONT

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	6	N	X	See M010A ENGINE MANAGEMENT ECU (FRONT)	1
				See M010A ENGINE MANAGEMENT ECU (FRONT)	2
				See M010A ENGINE MANAGEMENT ECU (FRONT)	4

A001C – Front

1.2 8v, 1.3 Multijet, 1.4 16v

Wiring	Colour
See 12 FRONT

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	10	N		See M086A ELECTRIC STEERING CONTROL UNIT (FRONT)	B

A001D – Battery positive

1.2 8v, 1.4 16v

Wiring	Colour
See 41 BATTERY POSITIVE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	16	R		See A020B STARTER MOTOR (BATTERY POSITIVE)	1

1.3 Multijet

Wiring	Colour
See 41 BATTERY POSITIVE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	35	R		See A020B STARTER MOTOR (BATTERY POSITIVE)	1

A001E – Battery positive

1.2 8v, 1.3 Multijet, 1.4 16v

Wiring	Colour
See 41 BATTERY POSITIVE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
	35	R		See B001A JUNCTION UNIT (BATTERY POSITIVE)	79
