A020 starter motor
- Make
- Fiat
- Model
- 500 Factory Service Manual
- Year
- 2007–2024
- Section
- Starting - recharging › A020 starter motor
Connectors and pin-outsA020 starter motor
A020 STARTER MOTOR
A020A – Engine
| Wiring | Colour |
|---|---|
| See 50 ENGINE |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 1.5 | M | See D004 FRONT/ENGINE COUPLING | G | |
| Wiring | Colour |
|---|---|
| See 50 ENGINE |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 2.5 | MB | See D004 FRONT/ENGINE COUPLING | 6 | |
A020B – Battery positive
| Wiring | Colour |
|---|---|
| See 41 BATTERY POSITIVE |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 16 | R | See A001D BATTERY (BATTERY POSITIVE) | 1 | ||
| Wiring | Colour |
|---|---|
| See 41 BATTERY POSITIVE |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 35 | R | See A001D BATTERY (BATTERY POSITIVE) | 1 | ||
A020C – Recharging
| Wiring | Colour |
|---|---|
| See 45 RECHARGING |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 10 | R | See A010B ALTERNATOR (RECHARGING) | 1 | ||
| Wiring | Colour |
|---|---|
| See 45 RECHARGING |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 16 | R | See A010B ALTERNATOR (RECHARGING) | 1 | ||
