CENTRAL LOCKING LOCATION COMPONENTS

Combi, Minibus, Panorama, Van

Location Components

Component code	Description	Reference to the assembly
B002	JUNCTION UNIT UNDER DASHBOARD
B099	MAXI FUSE BOX ON BATTERY
B101	OPTIONAL JUNCTION UNIT UNDER THE DASHBOARD
D016	ADDITIONAL DASHBOARD/LEFT FRONT DOOR COUPLING
D017	ADDITIONAL DASHBOARD/RIGHT FRONT DOOR COUPLING
D097	SHORT CIRCUITING COUPLING
D150	RIGHT REAR/RIGHT SWING DOOR COUPLING
D151	RIGHT SWING DOOR/RIGHT SWING DOOR LOCK COUPLING
D160	DASHBOARD/OPTIONAL DASHBOARD COUPLING
D172	RIGHT REAR/OPTIONAL DASHBOARD COUPLING
D173	RIGHT REAR/SLIDING SIDE DOOR BUTTON COUPLING
D185	CONTACT BOARD ON SLIDING SIDE DOOR
M135	ELECTRIC WINDOWS/CENTRAL LOCKING CONTROL UNIT
N050	DRIVER'S FRONT DOOR LOCK GEARED MOTOR
N051	RIGHT FRONT DOOR LOCK GEARED MOTOR
N054	RIGHT REAR SWING DOOR LOCK GEARED MOTOR

Chassis cab

Location Components

Component code	Description	Reference to the assembly
B002	JUNCTION UNIT UNDER DASHBOARD
B099	MAXI FUSE BOX ON BATTERY
B101	OPTIONAL JUNCTION UNIT UNDER THE DASHBOARD
D016	ADDITIONAL DASHBOARD/LEFT FRONT DOOR COUPLING
D017	ADDITIONAL DASHBOARD/RIGHT FRONT DOOR COUPLING
D097	SHORT CIRCUITING COUPLING
D150	RIGHT REAR/RIGHT SWING DOOR COUPLING
D151	RIGHT SWING DOOR/RIGHT SWING DOOR LOCK COUPLING
D160	DASHBOARD/OPTIONAL DASHBOARD COUPLING
D172	RIGHT REAR/OPTIONAL DASHBOARD COUPLING
D173	RIGHT REAR/SLIDING SIDE DOOR BUTTON COUPLING
D185	CONTACT BOARD ON SLIDING SIDE DOOR
M135	ELECTRIC WINDOWS/CENTRAL LOCKING CONTROL UNIT
N050	DRIVER'S FRONT DOOR LOCK GEARED MOTOR
N051	RIGHT FRONT DOOR LOCK GEARED MOTOR
N054	RIGHT REAR SWING DOOR LOCK GEARED MOTOR
