HEADLAMP WASHER - Wiring diagram

Wiring diagrams and electrical functionsHEADLAMP WASHER - Wiring diagram

Component code	Name	Assembly reference
A1	Battery	5530B
B1	Engine compartment junction unit	5505A
B2	Junction unit under dashboard	5505A
C10	Front left earth
C20	Passenger side dashboard earth
H1	Ignition switch	5520A
H5	Steering column switch unit	5550A
M1	Body computer	5505A
N25	Headlamp washer pump motor
