Wiring diagrams and electrical functionsHEATED SEATS - Wiring diagram
HEATED SEATS - Wiring diagram
Wiring diagram
COMPONENTS
| Component code | Name | Assembly reference |
|---|---|---|
| B1 | Engine compartment junction unit | 5505A |
| B2 | Junction unit under dashboard | 5505A |
| C20 | Passenger side dashboard earth | |
| C31 | Rear right earth | |
| D70 | Driver's seat coupling | |
| D71 | Passenger seat coupling | |
| D97 | Short circuiting coupling | |
| I65 | Switch for driver's heated seat | |
| I66 | Switch for heated passenger seat | |
| J62 | Seat heating relay | |
| M1 | Body computer | 5505A |
| O40 | Left seat heating resistance | |
| O41 | Right seat heating resistance |
