00 Introduction and technical dataFront brakes · page 2 of 3
| 1868 D | 1997 JTD | 1997 JTD 16v | |
|---|---|---|---|
| Type | mechanically operated |
rack and pinion with power steering |
|
| Ratio | steering wheel rotation |
4,6 | 3 |
rack travel |
– | 152 mm | |
| Minimum turning diameter |
11,6 m | 11,8 m (*) 13,2 m (**) |
|
| Steering angle | Outer wheel α₁ | – | 31° 29' 20" |
| Inner wheel α₂ | – | 36° 18' 34" | |
| Steering column | with two universal joints |
||
(*) Short wheelbase
(**) Long wheelbase
Original page
