00 Introduction and technical dataFront brakes · page 3 of 3
| WHEEL ALIGNMENT | 1868 D | 1997 JTD | 1997 JTD 16v |
|---|---|---|---|
| Camber (**) | 0° ±30' | ||
| Castor (**) | 3°30' ±30' | ||
| Front suspension toe-in | 1 ±0.5 mm | ||
| Camber (**) | 1° ±30' | – | |
| Castor (**) | – | ||
| Rear suspension toe-in (**) | 2 ±1 mm | – | |
(*) With tyres inflated to the prescribed pressure and vehicle in running order.
(**) Non-adjustable angles.
Original page
