Fiat Scudo Factory Service Manual (1996-2006)06 · 55 Electrical equipment
06 · Electrical

Connector a (page 2 of 2)

Make
Fiat
Model
Scudo Factory Service Manual
Year
1996–2006
Section
Instrument panel (2003 update)
55 Electrical equipmentConnector a · page 2 of 2

Connector a (page 2 of 2) – diagram from the 55 Electrical equipment chapter of the Fiat Scudo Factory Service Manual (1996-2006) factory manual.

Internal wiring diagram of the instrument panel with C26V and B18V connectors, components V4420, V4730, V4430, V4700, V1300, V6560, V2320, V2330, V0004, V7000, 3050, V4720, 4310, V4300, 4026, V4020, 4210, 4630, V4110, V1000, V8110, V2616, V2620, V2000, V4610 and digital display

* Speed limit exceedance acoustic indicator
