Lancia Thesis Factory Service Manual (2002-2009)19 · Wiring diagrams and electrical functions
19 · Electrical

Courtesy lights wiring diagram

Make
Lancia
Model
Thesis Factory Service Manual
Year
2002–2009
Section
Interior lighting › Courtesy lights wiring diagram
Wiring diagrams and electrical functionsCourtesy lights wiring diagram

COURTESY LIGHTS WIRING DIAGRAM

Passive Entry

Wiring Diagram

COURTESY LIGHTS WIRING DIAGRAM
COURTESY LIGHTS WIRING DIAGRAM

Components

Component codeNameAssembly reference
B002Junction unit under dashboard
B045Luggage compartment junction unit (CVB)5505A
C015Driver''s dashboard earth
C020
C022Centre dashboard earth
C030Left rear earth
D097Short circuit coupling
G0207040E
H001Ignition switch
I050Inertia switch1040A
M001Body computer
M0627040E
M063Luggage compartment control unit (NVB)
M064Passive entry control unit (NPE)5580E
P015Passive entry control unit RF aerial (NPE)

All versions

Wiring Diagram

COURTESY LIGHTS WIRING DIAGRAM
COURTESY LIGHTS WIRING DIAGRAM

Components

Component codeNameAssembly reference
B002Junction unit under dashboard
B045Luggage compartment junction unit (CVB)5505A
C015Driver''s dashboard earth
C022Centre dashboard earth
C030Left rear earth
D001
D097Short circuit coupling
G0207040E
H001Ignition switch
I050Inertia switch1040A
M001Body computer
M0627040E
M063Luggage compartment control unit (NVB)
P093Aerial for alarm and central locking receiver
