Wiring diagrams and electrical functionsDipped beams wiring diagram
DIPPED BEAMS WIRING DIAGRAM
Wiring Diagram
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B002 | Junction unit under dashboard | |
| C010 | Left front earth | |
| C011 | Right front earth | |
| C015 | Driver''s dashboard earth | |
| C022 | Centre dashboard earth | |
| F010 | 5540B | |
| F011 | 5540B | |
| H001 | Ignition switch | |
| H005 | Steering column switch unit | 5550A |
| H092 | Exterior light controls (CLE) | 5540A |
| M001 | Body computer | |
| M062 | 7040E | |
| M065 | Info-telematic control unit (NIT) | 5580P |
| K125 | RAIN, DUSK AND MISTING SENSOR |
