Fog lights wiring diagram
- Make
- Lancia
- Model
- Thesis Factory Service Manual
- Year
- 2002–2009
- Section
- Interior lighting › Fog lights wiring diagram
Wiring diagrams and electrical functionsFog lights wiring diagram
FOG LIGHTS WIRING DIAGRAM
Wiring Diagram
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B001 | Engine compartment junction unit | 5505A |
| B002 | Junction unit under dashboard | |
| C011 | Right front earth | |
| C022 | Centre dashboard earth | |
| D013 | Front/bumper coupling | |
| F015 | ||
| F016 | Right fog lamp | |
| E050 | Instrument panel | |
| H001 | Ignition switch | |
| H092 | Exterior light controls (CLE) | 5540A |
| M001 | Body computer |
