Wiring diagrams and electrical functionsInstrument lighting location components
INSTRUMENT LIGHTING LOCATION COMPONENTS
Location Components
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C011 | Right front earth | |
| C015 | Driver''s dashboard earth | |
| C020 | ||
| C022 | Centre dashboard earth | |
| C030 | Left rear earth | |
| D006 | Front/rear coupling | |
| D020 | ||
| D030 | Left front door coupling | |
| D031 | ||
| D032 | ||
| D035 | Left rear door coupling | |
| D036 | ||
| D037 | Giunzione posteriore / mobiletto centrale | |
| D047 | ||
| D070 | Driver''s seat coupling | |
| D071 | Passenger seat coupling | |
| D097 | Short circuit coupling | |
| D110 | CLOCK SPRING AND STEERING WHEEL CONTROLS COUPLING | |
| D131 | Right rear backrest cushion coupling | |
| D132 | Rear armrest backrest coupling | |
| E036 | Unit signalling driver''s front door locking/unlocking | |
| E037 | Unit signalling passenger front door locking/unlocking | |
| E038 | ||
| E039 | ||
| E050 | Instrument panel | |
| G035 | Ashtray light | |
| G037 | ||
| G042 | ||
| G043 | Passenger side rear ashtray light | |
| G065 | Left front door handle light | |
| G066 | ||
| G067 | ||
| G068 | Right rear door handle light | |
| H001 | Ignition switch | |
| H008 | ||
| H031 | Adjustable/folding mirrors control | 7005R |
| H036 | Controls on tunnel | |
| H053 | 7010M | |
| H054 | Electric window switch on right rear door | 7010M |
| H063 | ||
| H066 | 7045J | |
| H091 | Left control unit (PCS, left control panel) | 5540A |
| H092 | Exterior light controls (CLE) | 5540A |
| H093 | Steering wheel adjustment control unit | 4110A |
| I011 | Boot release switch | |
| I014 | Sun blind control switch | |
| I026 | Driver''s front door locking/unlocking switch | |
| I027 | Passenger front door locking/unlocking switch | |
| I028 | Driver''s rear door locking/unlocking switch | |
| I029 | ||
| I065 | ||
| I066 | ||
| M001 | Body computer | |
| M062 | 7040E | |
| M063 | Luggage compartment control unit (NVB) | |
| M065 | Info-telematic control unit (NIT) | 5580P |
| M066 | Driver''s door control unit (NPG) | 7005M |
| M067 | Passenger door control unit (NPP) | 7005M |
| M093 | STEERING WHEEL NODE CONTROL UNIT (NVO) |
