Land Rover Defender V8i Workshop Manual Supplement18 · Chassis and body
18 · Body & interior

Centre console refit

Make
Land Rover
Model
Defender V8i Workshop Manual Supplement
Section
Repair › Centre console refit
Chassis and bodyCentre console refit

CENTRE CONSOLE Refit

Service repair no - 76.25.01 12. Fit and align console.

  1. Fit and tighten screws securing console.

Remove 14. Fit tray to console.

  1. Fit hi-low gear lever knob and gaiter assembly.
  2. Open cubby box lid. 16. Secure hi-low gear lever gaiter to console.
  3. Fit gear selector housing surround and secure.
Centre console refit – Fit gear selector housing surround and secure.
  1. Fit cubby box to console and secure with
  2. Close cubby box lid.
  3. Remove 6 screws securing cubby box to console.
  4. Remove cubby box.
  5. Release rear edge of selector housing surround.
  6. Remove surround.
  7. Release hi-low gear lever gaiter from console.
  8. Remove hi-low gear lever knob and gaiter assembly.
  9. Remove tray from console.
  10. Remove screw securing front edge of console.
  11. Remove 3 screws securing rear of console.
  12. Remove console.

screws.
