300Tdi Defender
19
FUEL SYSTEM
6
DESCRIPTION AND OPERATION
TWIN TANK FUEL CHANGE - OVER MECHANISM
1. Change-over tap, fuel tanks
2. Fuel supply, side tank
3. Fuel supply, rear tank
4. To fuel lift pump
5. Change-over tap, spill return
6. Spill return, side tank
7. Spill return, rear tank
8. Spill return, injection pump to change-over tap
9. Control rod, operating lever to fuel change-over
tap
10. Control rod, change-over lever to spill return
pivot bracket
11. Fuel tank change-over switch
12. Control lever
