Discovery II
EXTERIOR FITTINGS
REPAIRS 76-2-13
Bumper assembly - rear - from 03MY
$% 76.22.15
Remove
1. Remove both rear tail lamps.
LIGHTING, REPAIRS, Lamp - tail/
2. Disconnect park distance control harness
multiplug.
3. Release rear lamp harness clips.
4. Remove 2 bolts securing bumper.
5. With assistance remove bumper.
NOTE: Do not carry out further dismantling if
component is removed for access only.
6. Remove 7 bolts and 5 screws securing closing
panel and remove panel.
M76 4566
