Discovery II
SUNROOF
76-6-20 REPAIRS
Switch pack - sunroof
$% 76.84.44
Remove
1. Release switch pack from front stowage
pocket.
2. Disconnect multiplugs from 3 sunroof
switches.
3. Remove switches from switch pack.
Refit
1. Fit switches to switch pack.
2. Connect multiplugs to switches.
3. Fit switch pack to front stowage pocket.
ECU - sunroof
$% 76.84.46
Remove
1. Remove front stowage pocket.
REPAIRS, Stowage pocket - front.
2. Remove 2 screws securing ECU to roof.
3. Disconnect 2 multiplugs from ECU.
4. Remove sunroof ECU.
Refit
1. Position sunroof ECU and connect multiplugs.
2. Fit and tighten screws securing ECU to roof.
3. Fit front stowage pocket.
