Range Rover P38
26
COOLING SYSTEM
NEW RANGE ROVER
6
REPAIR
WATER PUMP - UP TO 99MY
Service repair no - 26.50.01
Remove
1. Drain cooling system.
See this section.
2. Remove cooling fan.
See this section.
3. Slacken water pump pulley bolts.
4. Release tension from water pump drive belt.
Remove belt.
5. Remove water pump pulley.
6. Remove 9 bolts securing water pump.
7. Remove water pump and gasket.
Refit
8. Ensure mating faces are clean.
9. Fit water pump with new gasket.
10. Position water pump. Secure with bolts. Tighten
to
22 Nm (16 lbf.ft)
11. Fit water pump pulley. Secure with bolts.
Tighten to
22 Nm (16 lbf.ft)
12. Fit water pump drive belt.
13. Fit cooling fan.
See this section.
14. Fill cooling system.
See this section.
