Range Rover P38
75
SUPPLEMENTARY RESTRAINT SYSTEM
NEW RANGE ROVER
12
PRECAUTIONS
Deployment with module fitted to vehicle
These guidelines are written to aid authorised
personnel to carry out the safe disposal of airbag
modules and seatbelt pre-tensioner units when fitted
to the vehicle.
WARNING: Only use the Land Rover
approved deployment equipment. Deploy
airbag modules and seatbelt pre-tensioner
units in a well ventilated, designated area. Ensure
airbag module or seatbelt pre-tensioner unit is not
damaged or ruptured before deploying.
Driver’s airbag module
1. Carry out deployment tool self test.
2. Remove driver’s side fascia closing panel.
See
CHASSIS AND BODY, Repair.
3. Release airbag multiplug from fascia and
disconnect multiplug.
WARNING: Ensure tool SMD 4082/1 is not
connected to battery.
4. Connect flylead SMD 4082/5 to airbag
connector.
5. Connect flylead SMD 4082/5 to tool SMD
4082/1.
WARNING: Ensure airbag module is
secure within steering wheel.
6. Connect tool SMD 4082/1 to battery.
WARNING: Ensure all personnel are
standing at least 15 metres away from
vehicle.
