Range Rover P38
84
WIPERS AND WASHERS
NEW RANGE ROVER
4
REPAIR
REAR WIPER ARM
Service repair no - 84.35.01 - Wiper Arm
Service repair no - 84.35.02 - Wiper Blade
Remove
1. Remove wiper arm nut cover. Remove nut.
2. Remove wiper arm from motor spindle.
Wiper Blade
3. Release clip. Remove blade from arm
Refit
4. Fit wiper blade to arm.
5. Position arm to motor spindle. Secure with nut.
Tighten to
17 Nm (12 lbf.ft)
6. Fit nut cover.
