Range Rover P38
84
WIPERS AND WASHERS
NEW RANGE ROVER
8
REPAIR
WASHER RESERVOIR
Service repair no - 84.10.01
Remove
1. Raise the vehicle.
WARNING: Support on safety stands.
2. Remove RH wheel arch liner.
See CHASSIS
AND BODY, Repair.
3. Remove bolt and screw securing filler neck to
chassis and radiator bracket.
4. Remove filler neck.
5. Remove 2 bolts securing reservoir to chassis.
6. Release reservoir from mounting for access to
washer pumps.
7. Disconnect multiplugs and hoses from 3 washer
pumps.
8. Disconnect fluid level indicator multiplug.
9. Remove washer pumps and seals from
reservoir.
10. Remove filler neck seal.
Refit
11. Reverse removal procedure.
