OIL PUMP REMOVAL

• Turn the engine on the overhaul bench.

1. Loosen the fastening screws and remove the oil sump.

13 - 16 Nm
1.3 - 1.6 kgm

Proceed as follows (right-hand cylinder head only):

1. Lock engine oil pump drive pulley rotation with tool no. 1,822,146,000.
2. Loosen the fastening nut and remove the oil pump intermediate drive gear from its seat.

1,822,146,000

Remove the respective seals.

Loosen the fastening nuts and remove the engine crankcase cylinder head.

Loosen the fastening screws and remove the pump coolant return manifold.

6 ÷ 10 Nm
0.7 ÷ 1.1 kgm

Loosen the screws and remove the knock sensor.

Fit liner retainer tools no. 1,820,279,000.

1,820,279,000
