P020 radio

Make

Fiat

Model

500 Factory Service Manual

Year

2007–2024

Section

Various consumers › P020 radio

Connectors and pin-outsP020 radio

P020 RADIO

P020A – Dashboard

1.2 8v, 1.3 Multijet, 1.4 16v · Preparation for radio

Wiring	Colour
See 20 DASHBOARD	GRIGIO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
A4	1.5	RV		See M001E BODY COMPUTER (DASHBOARD)	12
A5	0.5	RG		See D020 DASHBOARD/REAR COUPLING	1
A6	0.35	GL		See M001D BODY COMPUTER (DASHBOARD)	60
A7	0.35	LV		See M001E BODY COMPUTER (DASHBOARD)	4
A8	1.5	N		See C015 DASHBOARD EARTH, DRIVER'S SIDE	1
B3	0.5	ZC		See D001 FRONT/DASHBOARD COUPLING	18
B4	0.5	ZN		See D001 FRONT/DASHBOARD COUPLING	17
B5	0.5	G		See D001 FRONT/DASHBOARD COUPLING	15
B6	0.5	GN		See D001 FRONT/DASHBOARD COUPLING	16

1.2 8v, 1.3 Multijet, 1.4 16v · HI-FI

Wiring	Colour
See 20 DASHBOARD	GRIGIO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
A1	0.35	L		See M001D BODY COMPUTER (DASHBOARD)	22
A3	0.35	B		See M001D BODY COMPUTER (DASHBOARD)	17
A4	1.5	RV		See M001E BODY COMPUTER (DASHBOARD)	12
A5	0.5	RG		See D020 DASHBOARD/REAR COUPLING	1
A8	1.5	N		See C015 DASHBOARD EARTH, DRIVER'S SIDE	1
B1	0.35	VR		See D020 DASHBOARD/REAR COUPLING	4
B2	0.35	VC		See D020 DASHBOARD/REAR COUPLING	5
B3	0.35	Z		See D020 DASHBOARD/REAR COUPLING	9
B4	0.35	ZL		See D020 DASHBOARD/REAR COUPLING	8
B5	0.35	GL		See D020 DASHBOARD/REAR COUPLING	12
B6	0.35	GV		See D020 DASHBOARD/REAR COUPLING	13
B7	0.35	CH		See D020 DASHBOARD/REAR COUPLING	2
B8	0.35	CL		See D020 DASHBOARD/REAR COUPLING	3

1.2 8v, 1.3 Multijet, 1.4 16v

Wiring	Colour
See 20 DASHBOARD	GRIGIO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
A1	0.35	L		See M001D BODY COMPUTER (DASHBOARD)	22
A3	0.35	B		See M001D BODY COMPUTER (DASHBOARD)	17
A4	1.5	RV		See M001E BODY COMPUTER (DASHBOARD)	12
A8	1.5	N		See C015 DASHBOARD EARTH, DRIVER'S SIDE	1
B1	0.5	V		See D020 DASHBOARD/REAR COUPLING	4
B2	0.5	VN		See D020 DASHBOARD/REAR COUPLING	5
B3	0.5	ZC		See D001 FRONT/DASHBOARD COUPLING	18
B4	0.5	ZN		See D001 FRONT/DASHBOARD COUPLING	17
B5	0.5	G		See D001 FRONT/DASHBOARD COUPLING	15
B6	0.5	GN		See D001 FRONT/DASHBOARD COUPLING	16
B7	0.5	C		See D020 DASHBOARD/REAR COUPLING	2
B8	0.5	CN		See D020 DASHBOARD/REAR COUPLING	3

P020B – Dashboard

1.2 8v, 1.3 Multijet, 1.4 16v

Wiring	Colour
See 20 DASHBOARD

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1				See D168 COAXIAL CABLE FOR RADIO AERIAL COUPLING	1

1.2 8v, 1.3 Multijet, 1.4 16v · Blue&Me, Bluetooth

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0.5	H		See D020 DASHBOARD/REAR COUPLING	16
2	0.5	V		See D020 DASHBOARD/REAR COUPLING	15
3	0.5	N-SCH		See D020 DASHBOARD/REAR COUPLING	14

P020C – Dashboard

1.2 8v, 1.3 Multijet, 1.4 16v · Blue&Me, Bluetooth

Wiring	Colour
See 20 DASHBOARD

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1				See D168 COAXIAL CABLE FOR RADIO AERIAL COUPLING	1
