P070 RADIO HI-FI AMPLIFIER

P070A – Rear

1.2 8v, 1.3 Multijet, 1.4 16v · HI-FI

Wiring	Colour
See 25 REAR	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0.35	ZL		See D020 DASHBOARD/REAR COUPLING	8
2	0.35	GV		See D020 DASHBOARD/REAR COUPLING	13
4	0.5	C		See P030 LEFT REAR SPEAKER	1
5	0.5	CN		See P030 LEFT REAR SPEAKER	2
6	1	G		See D020 DASHBOARD/REAR COUPLING	20
7	0.35	Z		See D020 DASHBOARD/REAR COUPLING	9
8	0.35	GL		See D020 DASHBOARD/REAR COUPLING	12
10	1.5	ZN		See D020 DASHBOARD/REAR COUPLING	11
11	1.5	ZC		See D020 DASHBOARD/REAR COUPLING	10
12	0.5	VN		See P031 RIGHT REAR SPEAKER	2
13	0.5	V		See P031 RIGHT REAR SPEAKER	1
14	1	GN		See D020 DASHBOARD/REAR COUPLING	19

P070B – Rear

1.2 8v, 1.3 Multijet, 1.4 16v · HI-FI

Wiring	Colour
See 25 REAR	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1.5	RG	X	See D006 FRONT/REAR COUPLING	12
				See P092 SUBWOOFER	3
2	1.5	N		See C030B LEFT REAR EARTH (REAR)	1
3	0.35	VC	X	See P092 SUBWOOFER	5
				See D020 DASHBOARD/REAR COUPLING	5
4	0.35	CL	X	See D020 DASHBOARD/REAR COUPLING	3
				See P092 SUBWOOFER	4
8	0.5	RG	X	See P092 SUBWOOFER	8
				See D020 DASHBOARD/REAR COUPLING	1
9	0.35	VR	X	See P092 SUBWOOFER	2
				See D020 DASHBOARD/REAR COUPLING	4
10	0.35	CH	X	See D020 DASHBOARD/REAR COUPLING	2
				See P092 SUBWOOFER	1
