P090 alarm siren
- Make
- Fiat
- Model
- Croma Factory Service Manual
- Year
- 2005–2010
- Section
- Various consumers › P090 alarm siren
Connectors and pin-outsP090 alarm siren
P090 ALARM SIREN
| Wiring | Colour |
|---|---|
| See 12 FRONT | NERO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 0,5 | R | See M001B BODY COMPUTER (FRONT) | 34 | |
| 2 | 0,35 | SR | See D097A SHORT CIRCUIT COUPLING (FRONT) | 2 | |
| 3 | 0,5 | N | See C011 RIGHT FRONT EARTH | 2 | |
