D097 SHORT CIRCUIT COUPLING

D097A – Front

Wiring	Colour
See 12 FRONT	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,35	SR		See M001B BODY COMPUTER (FRONT)	25
2	0,35	SR		See P090 ALARM SIREN	2
3	0,35	SR		See D001C FRONT/DASHBOARD COUPLING (FRONT)	17
6	0,75	AR		See B002A JUNCTION UNIT UNDER DASHBOARD (FRONT)	17
7	0,75	AR		See K064 EXHAUST GAS PRESENCE SENSOR	1
8	0,5	AR		See D004 FRONT/ENGINE COUPLING	32
9	0,5	AR		See M075 ADDITIONAL HEATER CONTROL UNIT	7

D097B – Front

XENON GAS HEADLAMPS

Wiring	Colour
See 12 FRONT	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	BL		See M075 ADDITIONAL HEATER CONTROL UNIT	5
2	0,35	BL		See M001B BODY COMPUTER (FRONT)	35
3	0,35	BL		See F010 LEFT HEADLAMP	11
4	0,35	BL		See F011 RIGHT HEADLAMP	11
5	0,5	BL		See D004 FRONT/ENGINE COUPLING	16

D097C – Dashboard

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,35	BS		See M001H BODY COMPUTER (DASHBOARD)	25
2	0,35	BS		See D047 CLOCK SPRING COUPLING	4
3	0,35	BS		See M089 STEERING LOCK CONTROL UNIT (NBS)	A2
4	0,35	BS		See P020A RADIO (DASHBOARD)	3
5	0,35	BS		See M060B AIR BAG CONTROL UNIT (DASHBOARD)	7
6	0,35	BS		See H003 IGNITION DEVICE	2
7	0,5	HM		See M089 STEERING LOCK CONTROL UNIT (NBS)	A5
8	0,5	HM		See I031 CLUTCH PEDAL SWITCH	4
9	0,5	HM		See D001B FRONT/DASHBOARD COUPLING (FRONT)	16

D097D – Dashboard

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,35	NS		See M001H BODY COMPUTER (DASHBOARD)	24
2	0,35	NS		See D047 CLOCK SPRING COUPLING	3
3	0,35	NS		See M089 STEERING LOCK CONTROL UNIT (NBS)	A3
4	0,35	NS		See P020A RADIO (DASHBOARD)	1
5	0,35	NS		See M060B AIR BAG CONTROL UNIT (DASHBOARD)	8
6	0,35	NS		See H003 IGNITION DEVICE	1
7	0,35	LN		See B002H JUNCTION UNIT UNDER DASHBOARD (DASHBOARD)	14
8	0,5	LN		See D021 DASHBOARD/AIR CONDITIONING-HEATER COUPLING	5
9	0,35	LN		See M001H BODY COMPUTER (DASHBOARD)	27

D097E – Dashboard

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,35	SR		See M047B TYRE INFLATION PRESSURE CONTROL UNIT (DASHBOARD)	18
2	0,35	SR		See D001C FRONT/DASHBOARD COUPLING (FRONT)	17
3	0,35	SR		See H005A STEERING COLUMN SWITCH UNIT (DASHBOARD)	2
6	0,5	RN		See M047A TYRE INFLATION PRESSURE CONTROL UNIT (DASHBOARD)	1
7	0,5	RN		See D021 DASHBOARD/AIR CONDITIONING-HEATER COUPLING	21
8	0,5	RN		See B002H JUNCTION UNIT UNDER DASHBOARD (DASHBOARD)	7

D097F – Dashboard

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	GR		See M001H BODY COMPUTER (DASHBOARD)	18
3	0,5	GR		See P020A RADIO (DASHBOARD)	6
4	0,5	GR		See P050 CIGAR LIGHTER / CURRENT SOCKET	1
6	0,5	GR		See D099 RADIO PHONE PREPARATION COUPLING	8
7	0,5	GN		See D154 DASHBOARD/BRAKE PEDAL SWITCH BRAID COUPLING	3
8	0,5	GN		See D001B FRONT/DASHBOARD COUPLING (FRONT)	14
9	0,5	GN		See M089 STEERING LOCK CONTROL UNIT (NBS)	C7

D097G – Dashboard

CONNECT NAV+

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,35	LG		See B002H JUNCTION UNIT UNDER DASHBOARD (DASHBOARD)	3
2	0,35	LG		See D047 CLOCK SPRING COUPLING	5
3	0,35	LG		See P020A RADIO (DASHBOARD)	4
4	0,35	LG		See D099 RADIO PHONE PREPARATION COUPLING	7
5	0,35	LG		See H036 CONTROLS ON TUNNEL	3
6	0,35	LG		See H091B LEFT CONTROL UNIT (PCS, LEFT CONTROL PANEL) (DASHBOARD)	17
7	0,35	LG		See D021 DASHBOARD/AIR CONDITIONING-HEATER COUPLING	2
8	0,5	LG		See H005C STEERING COLUMN SWITCH UNIT (DASHBOARD)	2
9	0,35	LG		See H036 CONTROLS ON TUNNEL	7

Radio setup

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,35	LG		See B002H JUNCTION UNIT UNDER DASHBOARD (DASHBOARD)	3
2	0,35	LG		See D047 CLOCK SPRING COUPLING	5
3	0,35	LG		See P020A RADIO (DASHBOARD)	7
4	0,35	LG		See D099 RADIO PHONE PREPARATION COUPLING	7
5	0,35	LG		See H036 CONTROLS ON TUNNEL	3
6	0,35	LG		See H091B LEFT CONTROL UNIT (PCS, LEFT CONTROL PANEL) (DASHBOARD)	17
7	0,35	LG		See D021 DASHBOARD/AIR CONDITIONING-HEATER COUPLING	2
8	0,5	LG		See H005C STEERING COLUMN SWITCH UNIT (DASHBOARD)	2
9	0,35	LG		See H036 CONTROLS ON TUNNEL	7

All versions

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,35	LG		See B002H JUNCTION UNIT UNDER DASHBOARD (DASHBOARD)	3
2	0,35	LG		See D047 CLOCK SPRING COUPLING	5
4	0,35	LG		See D099 RADIO PHONE PREPARATION COUPLING	7
5	0,35	LG		See H036 CONTROLS ON TUNNEL	3
6	0,35	LG		See H091B LEFT CONTROL UNIT (PCS, LEFT CONTROL PANEL) (DASHBOARD)	17
7	0,35	LG		See D021 DASHBOARD/AIR CONDITIONING-HEATER COUPLING	2
8	0,5	LG		See H005C STEERING COLUMN SWITCH UNIT (DASHBOARD)	2
9	0,35	LG		See H036 CONTROLS ON TUNNEL	7

D097H – Rear

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,35	BS		See B002D JUNCTION UNIT UNDER DASHBOARD (REAR)	10
2	0,35	BS		See D031 PASSENGER FRONT DOOR COUPLING	18
4	0,35	BS		See D030 DRIVER'S FRONT DOOR COUPLING	18
5	0,35	BS		See M063B LUGGAGE COMPARTMENT CONTROL UNIT (NVB) (REAR)	B7
6	0,35	BS		See M084A PARKING SENSOR CONTROL UNIT (REAR)	7
7	0,35	BS		See D070B DRIVER'S SEAT COUPLING (REAR)	8
8	0,35	BS		See D071B PASSENGER SEAT COUPLING (REAR)	8

D097I – Rear

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,35	NS		See B002D JUNCTION UNIT UNDER DASHBOARD (REAR)	28
2	0,35	NS		See D031 PASSENGER FRONT DOOR COUPLING	17
4	0,35	NS		See D030 DRIVER'S FRONT DOOR COUPLING	17
5	0,35	NS		See M063B LUGGAGE COMPARTMENT CONTROL UNIT (NVB) (REAR)	A7
6	0,35	NS		See M084A PARKING SENSOR CONTROL UNIT (REAR)	14
7	0,35	NS		See D070B DRIVER'S SEAT COUPLING (REAR)	9
8	0,35	NS		See D071A PASSENGER SEAT COUPLING (REAR)	9

D097J – Rear

POWERED SUNROOF

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,75	RV		See M001E BODY COMPUTER (REAR)	27
4	0,5	RV		See G010 FRONT COURTESY LIGHT	6
5	0,5	RV		See D045 SUN ROOF COUPLING	6
6	0,35	SR		See P065 ELECTRO-CHROMIC INTERIOR REAR VIEW MIRROR	5
7	0,35	SR		See K062 VOLUMETRIC SENSORS FOR ALARM	4
8	0,35	SR		See M001D BODY COMPUTER (REAR)	7

All versions

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,75	RV		See M001E BODY COMPUTER (REAR)	27
2	0,5	RV		See D169 REAR COUPLING / REAR COURTESY LIGHT BRAID	1
3	0,5	RV		See D169 REAR COUPLING / REAR COURTESY LIGHT BRAID	4
4	0,5	RV		See G010 FRONT COURTESY LIGHT	6
6	0,35	SR		See P065 ELECTRO-CHROMIC INTERIOR REAR VIEW MIRROR	5
7	0,35	SR		See K062 VOLUMETRIC SENSORS FOR ALARM	4
8	0,35	SR		See M001D BODY COMPUTER (REAR)	7

D097K – Rear

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	LR		See B002D JUNCTION UNIT UNDER DASHBOARD (REAR)	19
2	0,35	LR		See H073 SUN ROOF BLIND CONTROLS	3
3	0,35	LR		See M084A PARKING SENSOR CONTROL UNIT (REAR)	1
4	0,35	LR		See K062 VOLUMETRIC SENSORS FOR ALARM	3
5	0,35	LR		See D071B PASSENGER SEAT COUPLING (REAR)	2
6	0,35	LR		See D070B DRIVER'S SEAT COUPLING (REAR)	2
7	1,5	BG		See B002D JUNCTION UNIT UNDER DASHBOARD (REAR)	12
8	1,5	BG		See D020A DASHBOARD/REAR COUPLING (DASHBOARD)	11
9	0,75	BG		See B045A LUGGAGE COMPARTMENT JUNCTION UNIT (CVB) (REAR)	25

D097L – Rear

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,35	GV		See M001E BODY COMPUTER (REAR)	40
2	0,5	GV		See P052 REAR CURRENT SOCKET	1
4	0,35	GV		See P065 ELECTRO-CHROMIC INTERIOR REAR VIEW MIRROR	1
