D070 driver''s seat coupling

Make

Fiat

Model

Croma Factory Service Manual

Year

2005–2010

Section

Intermediate couplings › D070 driver''s seat coupling

Connectors and pin-outsD070 driver''s seat coupling

D070 DRIVER''S SEAT COUPLING

D070A – Rear

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	H		See M060A AIR BAG CONTROL UNIT (REAR)	6
2	0,5	B		See M060A AIR BAG CONTROL UNIT (REAR)	5
3	0,35	CB		See M060A AIR BAG CONTROL UNIT (REAR)	19
4	0,35	NZ		See C050B AIR BAG SYSTEM EARTH (REAR)	6
5	0,35	NZ		See C050B AIR BAG SYSTEM EARTH (REAR)	7
7	0,5	Z		See M060A AIR BAG CONTROL UNIT (REAR)	14
8	0,5	V		See M060A AIR BAG CONTROL UNIT (REAR)	13

D070A – Left seat

Wiring	Colour
See 36 LEFT SEAT	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5			See Q020 DRIVER'S SIDE FRONT BELT PRETENSIONER	1
2	0,5			See Q020 DRIVER'S SIDE FRONT BELT PRETENSIONER	2
3	0,35			See Q020 DRIVER'S SIDE FRONT BELT PRETENSIONER	3
4	0,35			See Q020 DRIVER'S SIDE FRONT BELT PRETENSIONER	4
5	0,5	N		See Q030 DRIVER'S SIDEBAG	3
7	0,5	CN		See Q030 DRIVER'S SIDEBAG	1
8	0,5	AG		See Q030 DRIVER'S SIDEBAG	2

D070B – Rear

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1	CN		See B045A LUGGAGE COMPARTMENT JUNCTION UNIT (CVB) (REAR)	6
2	0,35	LR		See D097K SHORT CIRCUIT COUPLING (REAR)	5
3	1	N		See C015 DRIVER'S DASHBOARD EARTH	6
6	2,5	N		See C015 DRIVER'S DASHBOARD EARTH	7
7	2,5	SB		See B045A LUGGAGE COMPARTMENT JUNCTION UNIT (CVB) (REAR)	3
8	0,35	BS		See D097H SHORT CIRCUIT COUPLING (REAR)	7
9	0,35	NS		See D097I SHORT CIRCUIT COUPLING (REAR)	7
10	0,35	NZ		See C015 DRIVER'S DASHBOARD EARTH	12

D070B – Left seat

Wiring	Colour
See 36 LEFT SEAT	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1	M	X	See M170 DRIVE SIDE FRONT PASSENGER SEAT HEATER CONTROL UNIT	5
				See I065 DRIVER'S SEAT HEATING SWITCH	2
2	1	R		See I065 DRIVER'S SEAT HEATING SWITCH	1
6	2,5	N		See M173B DRIVE ALIGNMENT NODE (LEFT SEAT)	5
7	2,5	B		See M173B DRIVE ALIGNMENT NODE (LEFT SEAT)	9
8	0,35	C		See M173A DRIVE ALIGNMENT NODE (LEFT SEAT)	6
9	0,35	BR		See M173A DRIVE ALIGNMENT NODE (LEFT SEAT)	5
10	0,35	LN		See M173A DRIVE ALIGNMENT NODE (LEFT SEAT)	8
12	1	N	X	See I065 DRIVER'S SEAT HEATING SWITCH	5
				See M170 DRIVE SIDE FRONT PASSENGER SEAT HEATER CONTROL UNIT	4
				See O048 LEFT FRONT BACKREST HEATER PAD	3
				See O046 LEFT FRONT SEAT HEATER PAD WITH SENSOR	4
