D068 hi-fi system coupling

Make

Fiat

Model

Croma Factory Service Manual

Year

2005–2010

Section

Intermediate couplings › D068 hi-fi system coupling

Connectors and pin-outsD068 hi-fi system coupling

D068 HI-FI SYSTEM COUPLING

D068A – Hi fi system bridge

Wiring	Colour
See 59 HI FI SYSTEM BRIDGE	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,35	BZ		See P070 RADIO HI-FI AMPLIFIER	C7
2	0,35	NZ		See P070 RADIO HI-FI AMPLIFIER	B7
3	0,35	MN		See P070 RADIO HI-FI AMPLIFIER	C5
4	0,35	MV		See P070 RADIO HI-FI AMPLIFIER	B5
5	0,35	BN		See P070 RADIO HI-FI AMPLIFIER	C4
6	0,35	AN		See P070 RADIO HI-FI AMPLIFIER	B4
7	0,35	HL		See P070 RADIO HI-FI AMPLIFIER	C6
8	0,35	LR		See P070 RADIO HI-FI AMPLIFIER	B6
9	0,5	BC		See P070 RADIO HI-FI AMPLIFIER	C2
10	0,5	B		See P070 RADIO HI-FI AMPLIFIER	C3

D068A – Dashboard

CONNECT NAV+, HI-FI

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	AR		See P020B RADIO (DASHBOARD)	5
2	1,5	MN		See P020B RADIO (DASHBOARD)	6
3	1,5	BG		See P020B RADIO (DASHBOARD)	7
4	1,5	NR		See P020B RADIO (DASHBOARD)	8
5	1,5	GN		See P020B RADIO (DASHBOARD)	1
6	1,5	NZ		See P020B RADIO (DASHBOARD)	2
7	1,5	CN		See P020B RADIO (DASHBOARD)	3
8	1,5	NV		See P020B RADIO (DASHBOARD)	4
9	0,5	BC		See P020C RADIO (DASHBOARD)	6
10	0,5	S		See P020A RADIO (DASHBOARD)	2

D068B – Hi fi system bridge

Wiring	Colour
See 59 HI FI SYSTEM BRIDGE	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	BG		See P070 RADIO HI-FI AMPLIFIER	A6
2	1,5	BR		See P070 RADIO HI-FI AMPLIFIER	A7
3	1,5	AG		See P070 RADIO HI-FI AMPLIFIER	A2
4	1,5	AB		See P070 RADIO HI-FI AMPLIFIER	A3
5	1,5	GR		See P070 RADIO HI-FI AMPLIFIER	B2
6	1,5	GN		See P070 RADIO HI-FI AMPLIFIER	B3
7	1,5	CN		See P070 RADIO HI-FI AMPLIFIER	A4
8	1,5	CB		See P070 RADIO HI-FI AMPLIFIER	A5

D068B – Rear

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	AR		See D030 DRIVER'S FRONT DOOR COUPLING	25
2	1,5	MN		See D030 DRIVER'S FRONT DOOR COUPLING	24
3	1,5	BG		See D035 LEFT REAR DOOR COUPLING	C5
4	1,5	NR		See D035 LEFT REAR DOOR COUPLING	C6
5	1,5	GN		See D036 RIGHT REAR DOOR COUPLING	C5
6	1,5	NZ		See D036 RIGHT REAR DOOR COUPLING	C6
7	1,5	CN		See D031 PASSENGER FRONT DOOR COUPLING	25
8	1,5	NV		See D031 PASSENGER FRONT DOOR COUPLING	24

D068C – Hi fi system bridge

Wiring	Colour
See 59 HI FI SYSTEM BRIDGE	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
A	2,5	R		See P070 RADIO HI-FI AMPLIFIER	C8
C	2,5	N		See P070 RADIO HI-FI AMPLIFIER	C1

D068C – Rear

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
A	2,5	R		See B045A LUGGAGE COMPARTMENT JUNCTION UNIT (CVB) (REAR)	1
C	2,5	N		See C030 LEFT REAR EARTH	7
