D020 dashboard/rear coupling

Make

Fiat

Model

Croma Factory Service Manual

Year

2005–2010

Section

Intermediate couplings › D020 dashboard/rear coupling

Connectors and pin-outsD020 dashboard/rear coupling

D020 DASHBOARD/REAR COUPLING

D020A – Dashboard

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,35	AL		See P020F RADIO (DASHBOARD)	18
2	0,35	AB		See P020F RADIO (DASHBOARD)	9
3	0,5	GR		See M047A TYRE INFLATION PRESSURE CONTROL UNIT (DASHBOARD)	2
8	0,35	LS		See H036 CONTROLS ON TUNNEL	6
9	0,35	BM		See H036 CONTROLS ON TUNNEL	5
10	0,35	AG	X	See H005B STEERING COLUMN SWITCH UNIT (DASHBOARD)	6
				See M001G BODY COMPUTER (DASHBOARD)	30
11	1,5	BG		See P050 CIGAR LIGHTER / CURRENT SOCKET	2
12	0,35	GN		See M047A TYRE INFLATION PRESSURE CONTROL UNIT (DASHBOARD)	4
13	0,35	MV		See M047B TYRE INFLATION PRESSURE CONTROL UNIT (DASHBOARD)	15
14	0,35	SV		See M047A TYRE INFLATION PRESSURE CONTROL UNIT (DASHBOARD)	6
15	0,35	NS		See M047B TYRE INFLATION PRESSURE CONTROL UNIT (DASHBOARD)	13
16	0,35	LZ		See M047A TYRE INFLATION PRESSURE CONTROL UNIT (DASHBOARD)	3
17	0,35	NV		See M047B TYRE INFLATION PRESSURE CONTROL UNIT (DASHBOARD)	12
18	0,35	LG		See M047A TYRE INFLATION PRESSURE CONTROL UNIT (DASHBOARD)	5
19	0,35	NZ		See M047B TYRE INFLATION PRESSURE CONTROL UNIT (DASHBOARD)	14
20	0,35	BL		See M047B TYRE INFLATION PRESSURE CONTROL UNIT (DASHBOARD)	17

D020A – Rear

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,35	AL		See P026 HANDSFREE MICROPHONE	2
2	0,35	AB		See P026 HANDSFREE MICROPHONE	1
3	0,5	GR	X	See D006 FRONT/REAR COUPLING	13
				See D155 FRONT/REAR SERVICE CABLES COUPLING	12
8	0,35	LS		See D030 DRIVER'S FRONT DOOR COUPLING	16
9	0,35	BM		See D030 DRIVER'S FRONT DOOR COUPLING	15
11	1,5	BG		See D097K SHORT CIRCUIT COUPLING (REAR)	8
12	0,35	GN		See D006 FRONT/REAR COUPLING	19
13	0,35	MV		See D006 FRONT/REAR COUPLING	18
14	0,35	SV		See D155 FRONT/REAR SERVICE CABLES COUPLING	4
15	0,35	NS		See D155 FRONT/REAR SERVICE CABLES COUPLING	5
16	0,35	LZ		See D155 FRONT/REAR SERVICE CABLES COUPLING	7
17	0,35	NV		See D155 FRONT/REAR SERVICE CABLES COUPLING	6
18	0,35	LG		See D006 FRONT/REAR COUPLING	17
19	0,35	NZ		See D006 FRONT/REAR COUPLING	14
20	0,35	BL		See M001D BODY COMPUTER (REAR)	18

D020B – Dashboard

Radio setup

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	AR		See P020B RADIO (DASHBOARD)	5
2	1,5	MN		See P020B RADIO (DASHBOARD)	6
3	1,5	BG		See P020B RADIO (DASHBOARD)	7
4	1,5	NR		See P020B RADIO (DASHBOARD)	8
5	1,5	GN		See P020B RADIO (DASHBOARD)	1
6	1,5	NZ		See P020B RADIO (DASHBOARD)	2
7	1,5	CN		See P020B RADIO (DASHBOARD)	3
8	1,5	NV		See P020B RADIO (DASHBOARD)	4
10	0,5	S		See P020A RADIO (DASHBOARD)	5

All versions

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	AR		See P020B RADIO (DASHBOARD)	5
2	1,5	MN		See P020B RADIO (DASHBOARD)	6
3	1,5	BG		See P020B RADIO (DASHBOARD)	7
4	1,5	NR		See P020B RADIO (DASHBOARD)	8
5	1,5	GN		See P020B RADIO (DASHBOARD)	1
6	1,5	NZ		See P020B RADIO (DASHBOARD)	2
7	1,5	CN		See P020B RADIO (DASHBOARD)	3
8	1,5	NV		See P020B RADIO (DASHBOARD)	4

D020B – Rear

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	AR		See D030 DRIVER'S FRONT DOOR COUPLING	25
2	1,5	MN		See D030 DRIVER'S FRONT DOOR COUPLING	24
3	1,5	BG		See D035 LEFT REAR DOOR COUPLING	C5
4	1,5	NR		See D035 LEFT REAR DOOR COUPLING	C6
5	1,5	GN		See D036 RIGHT REAR DOOR COUPLING	C5
6	1,5	NZ		See D036 RIGHT REAR DOOR COUPLING	C6
7	1,5	CN		See D031 PASSENGER FRONT DOOR COUPLING	25
8	1,5	NV		See D031 PASSENGER FRONT DOOR COUPLING	24
