Wiring diagrams and electrical functionsAdditional heater - wiring diagram
ADDITIONAL HEATER - WIRING DIAGRAM
Components
| Component code | Description | Reference to the assembly |
|---|---|---|
| B001 | ENGINE COMPARTMENT JUNCTION UNIT | Op. 5505A MULTI-FUNCTION COMPONENTS |
| B002 | JUNCTION UNIT UNDER DASHBOARD | Op. 5505A MULTI-FUNCTION COMPONENTS |
| B099 | MAXI FUSE BOX ON BATTERY | Op. 5530B BATTERY AND LEADS |
| C011 | RIGHT FRONT EARTH | |
| C030 | LEFT REAR EARTH | |
| D001 | FRONT/DASHBOARD COUPLING | |
| D006 | FRONT/REAR COUPLING | |
| D021 | DASHBOARD/AIR CONDITIONING-HEATER COUPLING | |
| D097 | SHORT CIRCUIT COUPLING | |
| D213 | FUEL TANK COUPLING | |
| I050 | INERTIA SWITCH | Op. 1040A FUEL TANK AND COMPONENTS |
| M070 | CLIMATE CONTROL SYSTEM CONTROL UNIT | Op. 5040D AIR CONDITIONING CONTROLS |
| M075 | ADDITIONAL HEATER CONTROL UNIT | |
| N044 | ADDITIONAL HEATER ELECTRIC PUMP |
